Key Features

• Automated Reporting: Prints the scan plan and B-Scans with a click of a button.
• Overlay Multiple B-Scans: Compare different scans by overlaying them for detailed analysis.
• Data Tables: Generate tables showing high, average, and low values for each scan.
• Re-Gating Function: Re-gate scan data post-collection to create smooth, clean scan maps.
• Statistical Analysis: Perform automated statistical analysis on scan data.

System Features

• User-Friendly Interface: Easy navigation through setup, analysis, and reporting.
• Guided Calibration: Assists users through the calibration process.
• Automated Data Acquisition: Streamlines the scanning process.
• Adjustable Gain: Modify gain before or during the scan to optimize data return.
• Real-Time View: Monitor data in real-time and make adjustments during the scan.
• Repositioning: Pause and resume scans seamlessly, with the ability to reposition the scanner.

Reporting

Generating reports is fast and easy with Analyst X™. Automated reporting includes scan plan information and B-Scans associated with the vessel. Create B-Scan overlays for comparison and print charts showing the high, average, and low thickness values of each scan. Data tables and C-Scan views can also be printed for comprehensive reporting.

Re-Gating

The re-gating function allows users to clean up data by re-gating selected regions or entire scans to reduce noise interference. Gates are easy to manipulate, adjusted simply by clicking and dragging.

Real-Time View

As the scanner maps corrosion, data appears on the screen in real-time. This allows for immediate monitoring and gain adjustments during the scan for optimal results.

Analysis

Post-scan, users can add weld lines, flag values, re-gate data, and perform statistical analysis to get the most accurate and detailed results.

Adaptability

Analyst X™ is initially configured for use with the X2-X3 Spider System for tank inspections. For dryer roll inspections, the system can be enhanced by adding the D2S add-in to the Analyst X software. This upgrade transitions the system to a Dual-Channel Dryer Scanning System. Additional components, such as a second channel for the X Controller, D2S calibration blocks, D2S wedge, D2S jumper cables, and D2S main cable, are then integrated to complete the D2S system.

System Requirements

• OS: Windows 10/8.1/8/7 (32 and 64-bit)
• Processor: Any Intel or AMD x86-64 processor
• RAM: 4 GB (8 GB minimum, 16 recommended)
• Disk Space: 1 TB
• Graphics: No specific graphics card required
