X Controller

Key Features

• Integrated Motion Control and Ultrasonic Unit: Combines both functionalities into a single, compact unit.
• Standard Configuration: Includes velocity control wheel and transducers.
• Emergency Stop Button: Front-mounted for added safety.
• LED Indicators: Rear-panel lights show power status at a glance.
• Compact and Portable: Weighs only 11 lb (5 kg) at 0.51 ft³, easy to carry and store.

Ultrasonic Instrumentation

Controller Specifications

• Power: 12–24 VDC, 240 W max
• AC Supply: 90–240 VAC, 280 W
• Dimensions: 9.25 × 12.75 × 7.5 in (235 × 324 × 191 mm)
• Weight: 11 lb (5 kg)

Outputs & Interfaces

• Scanner Control & Power
• Isolated Encoder Signals (optional)
• Data & Control: Gigabit Ethernet
• Onboard Display: Color 1/4″ VGA touchscreen
